Features:
Special structure, compact size, wide measuring range, high accuracy and good anti-eccentric load capacity, excellent stability and sealing performance.
Application fields:
Truck scales, tank scales, batching scales, warehouse scales, etc.
Capacity
| Parameter | Unit | Specification | Parameter | Unit | Specification |
|---|---|---|---|---|---|
| Sensitivity | mV/V | 1.0~2.0+0.05 | Temp. Coeff. of Sensitivity | %F·S/10°C | ±0.1 |
| Non-linearity | %F·S | ±0.3 | Operating Temp. Range | °C | -20~+80 |
| Hysteresis | %F·S | ±0.1 | Input Resistance | Ω | 350±50 |
| Repeatability | %F·S | ±0.1 | Output Resistance | Ω | 350±5 |
| Creep (30min) | %F·S/30min | ±0.1 | Safe Overload | %F·S | 150 |
| Zero Balance | %F·S | ±1 | Insulation Resistance | MΩ | ≥2000 |
| Temp. Coeff. of Zero | %F·S/10°C | ±0.1 | Recommended Excitation Voltage | V | 5~15 |
